TL;DR: Modders led by TunerTom expanded the original PlayStation’s RAM from 2MB to 16MB by replacing four 512KB DRAM chips with eight 2MB chips and custom wiring, enabling arcade-compatible memory support. The complex mod suits skilled technicians, breaks compatibility for some commercial games, but benefits homebrew and ports.
Voice: Hassam NasirSpeed
0:00 / 3:31
Use left and right arrow keys to seek audio.
Modders are always looking for ways to improve old hardware while preserving its soul. A new hardware mod has pushed the original 1994 PlayStation well past its factory spec, expanding system RAM from 2MB to 16MB. The project comes from modder TunerTom, working with the PSX.dev Discord community, and was demonstrated on video by Tito Perez of Macho Nacho Productions
The mod isn’t adding new capability so much as unlocking something that was already there. The upgrade activates memory support that Sony originally built for its arcade hardware but never enabled on retail consoles. TunerTom reportedly studied those arcade boards, which used two 8MB memory banks, and found the PS1’s CPU could address the same configuration
The install itself, however, is far from simple. The console detects the upgrade as two separate 8MB banks, and getting there means replacing the four factory 512KB EDO DRAM chips with eight 2MB chips pulled from old PC memory modules. Four chips go in normally, while the other four are stacked on top of them, with custom wiring and trace cuts needed to route the signals correctly
5
VIEW GALLERY – 5 IMAGES
It’s a job for someone comfortable with a soldering iron and a hot air gun, not a weekend project for casual owners. It reportedly only works cleanly on PU-8 motherboards, like those found in SCPH-5500 consoles. Clearly, this mod is not for everyone and requires someone who actually knows what they’re getting into
5
As for what it actually does, don’t expect a night-and-day difference on your favorite PS1 classics. Retail games generally continue to use the original 2MB allocation, and the modification isn’t fully compatible with every title; Final Fantasy IX reportedly failed to boot past the PlayStation logo during testing. No commercial game currently uses the full 16MB, since none were coded with that much memory in mind
5
So is it useless? Well, the real upside is for homebrew developers. With eight times the memory to work with, coders could patch existing games for higher detail models or longer draw distances, or build entirely new ports. One example already floating around is a version of Super Mario 64 built to run from the PS1’s expanded memory pool. This could develop into something really cool down the line if enough attention is given to it
5
Question #1
Which PS1 motherboard revisions besides PU-8 are compatible or incompatible with this 16MB RAM mod?
Question #2
Does the mod require any BIOS or bootloader changes, or is it purely hardware-level modifications?
Question #3
Which commercial PS1 titles have been tested and are known to fail or partially work with the 16MB upgrade?
Question #4
Are there documented homebrew projects or ports (like the Super Mario 64 build) that currently take advantage of the expanded memory?
Have a question not listed here? Ask below and TweakBot will answer it
For now, this remains a niche project for retro modders rather than something the average PS1 owner should attempt, but it’s a good reminder that three-decade-old hardware can still surprise people. It is also nice to see the modding community trying to put a fresh coat of paint on the original PlayStation
